travelling gantry crane

Authentication mark:

Capacity:

1t – 500t

Lifting Height:

6m – 45m

Span:

5.5m – 35m

Voltage/Hertz:

AC380V 50Hz 3

Working Class:

A3 – A7

Get A Free Quote

Introduction

Application Scenario

Advantages

Structural Diagram And Parameter Table

INTRODUCTION

The travelling gantry crane is a heavy-duty material handling solution designed for outdoor and semi-outdoor operations. It features a bridge beam supported by two rigid legs that travel along ground-level rails, enabling efficient lifting and transportation of heavy loads across large work areas.

Built with high-strength steel and equipped with advanced electrical systems, the travelling gantry crane delivers reliable performance in demanding industrial environments. Available in single girder and double girder configurations, it can be customized to meet specific capacity, span, and height requirements. With ISO/CE/ASME certifications, our cranes are engineered for safety, durability, and long-term service life.

APPLICATION SCENARIO

Application Area

Shipyard Hull assembly, section turning, block erection, launching operations Port & Dock Container handling, bulk cargo loading/unloading, heavy equipment transfer

Steel & Metallurgy Steel billet, coil, rebar handling, furnace charging, scrap yard operations

Heavy Machinery Manufacturing Assembly line material feeding, finished product handling

Warehouse & Storage Yard Heavy cargo stacking, loading/unloading trucks and trains Construction & Precast Yard Precast concrete element lifting, steel structure installation Power Plant & Dam Turbine maintenance, heavy equipment installation, construction material handling

ADVANTAGES

Why Choose Us

20+ years manufacturing experience

ISO 9001 / CE / ASME certified

100+ countries project references

Custom engineering capability for non-standard requirements

Free design consultation with professional engineering team

Factory direct pricing with competitive rates

Comprehensive after-sales service and warranty support

STRUCTURAL DIAGRAM AND PARAMETER TABLE

Parameter	Value / Range
Lifting Capacity	1t – 500t
Span	5.5m – 35m
Lifting Height	6m – 45m
Work Duty Class (ISO/FEM)	A3 – A7
Hoisting Speed	4.6 – 18 m/min
Crane Travel Speed	6 – 60 m/min
Max Wheel Load	280 – 340 KN
Working Temperature	-20°C to +40°C
Structure Type	Single girder / Double girder

Six core advantages

Full Scenario Coverage

Nucleon covers over 20 product categories including ladle cranes, multi-purpose cranes, intelligent cranes, overhead/portal cranes, RTG, RMG, deck cranes, portal cranes, girder launchers, yacht cranes, KBK, and jib cranes. From steel smelting to port handling, bridge construction to ship equipment, Nucleon provides one-stop lifting solutions. Whether standard models or extreme-condition customizations, Nucleon possesses mature technical expertise and proven track records, saving customers from dealing with multiple suppliers.

Military-Grade Quality Standards

We use high-strength steel from Baosteel/Ansteel for key structural components, with 100% NDT inspection and one-clamp CNC gantry machining. Every machine undergoes 120% dynamic load and 125% static load tests before delivery, with continuous operation verification under extreme conditions. Even in 24/7 continuous casting plants, -40°C arctic ports, or high-temperature humid ship cabins, our cranes maintain millimeter-level precision and zero-drift stability—quality that stands the test of time.

Extended Longevity & Low Maintenance Cost

Our main girders are FEA-optimized and double-submerged arc welded, with a design life of ≥30 years. Key bearings are lifetime lubrication-free, and hardened travel wheels extend wear cycles by 3 times. Core components feature modular quick-change interfaces with spare parts commonality exceeding 80%. Annual maintenance costs are reduced by 40%~60%, saving millions in lifecycle operating expenses — truly "invest once, benefit long-term."

Energy Efficiency Leader

Our entire series comes standard with IE5 permanent magnet synchronous motors + energy feedback VFD drives, achieving 25%~35% comprehensive energy savings. Single-motor operation under light loads and adaptive speed control reduce electrical waste by over 30%. High-strength steel lightweight design cuts deadweight by 15%~20%, lowering workshop load requirements. A single ladle crane station saves over RMB 150,000 in electricity costs annually, helping customers achieve green and low-carbon production.

Ultimate Safety Redundancy Design

Our hoisting mechanism comes standard with dual brakes + mechanical overspeed switch + triple limit switches, featuring multiple redundant interlocks to prevent load dropping and over-traveling. Large products use box girder torsion-resistant structures, remaining stable even in level 8 gusty winds. Optional intelligent safety monitoring systems detect anomalies in load, skew, wind speed, etc., with automatic alarms and shutdowns. Overall safety redundancy coefficient > 2.0, maintaining zero crane safety incidents for many consecutive years.

Deep Customization & Full Lifecycle Service

We provide complete front-end support from site survey and mechanical simulation to civil review, delivering custom drawings within 2 weeks, with non-standard lead times only 5~7 days longer than standard products. We establish lifelong digital dossiers for customers, warning of end-of-life components 3 months in advance. Our full lifecycle services cover installation training, regular inspections, and remote O&M. With customer repeat purchase rates exceeding 85% for five consecutive years, we are a trustworthy long-term partner.
